| Difficulty: Intermediate | Category: Ai Tools |
Build a Real-Time Shipping Route Alert System Using Maritime AI APIs and Geopolitical Data
With Trump announcing U.S. intervention to free ships in the Strait of Hormuz starting Monday, global supply chains face immediate uncertainty. Over 20% of the world’s petroleum passes through this 21-mile-wide chokepoint—any disruption cascades into delays worth millions. By the end of this tutorial, you’ll deploy an AI-powered monitoring system that tracks ship movements through critical maritime zones, analyzes geopolitical news in real-time, and sends actionable alerts when route disruptions occur.
Prerequisites
Before starting, ensure you have:
- Python 3.11+ with pip installed
- Anthropic API key (Claude Sonnet 3.5 costs $3/M input tokens, $15/M output tokens)
- MarineTraffic API account (free tier: 100 requests/day) or AIS Stream API ($29/month for real-time data)
- Twilio account for SMS alerts (free trial includes $15 credit)
- Basic familiarity with cron jobs or GitHub Actions for scheduling
Step-by-Step Guide
Step 1: Set Up Your Maritime Data Pipeline
Install the required dependencies and configure your API credentials:
pip install anthropic requests python-dotenv twilio geopy pandas
Create a .env file in your project root:
ANTHROPIC_API_KEY=sk-ant-api03-...
MARINETRAFFIC_API_KEY=your_mt_key_here
TWILIO_ACCOUNT_SID=AC...
TWILIO_AUTH_TOKEN=your_auth_token
TWILIO_FROM_NUMBER=+1234567890
ALERT_TO_NUMBER=+1987654321
⚠️ WARNING: Never commit .env to version control. Add it to .gitignore immediately.
Step 2: Query Live Ship Positions in Critical Zones
The Strait of Hormuz sits between coordinates (26.5°N, 56.0°E) and (25.5°N, 57.0°E). Use MarineTraffic’s Area API to fetch all vessels currently transiting:
import requests
import os
from dotenv import load_dotenv
load_dotenv()
def get_ships_in_hormuz():
"""Fetch all vessels in Strait of Hormuz bounding box."""
url = "https://services.marinetraffic.com/api/exportvessels/v:8/"
params = {
"MINLAT": 25.5,
"MAXLAT": 26.5,
"MINLON": 56.0,
"MAXLON": 57.0,
"timespan": 20, # vessels active in last 20 minutes
"protocol": "json"
}
headers = {"API-Key": os.getenv("MARINETRAFFIC_API_KEY")}
response = requests.get(url, params=params, headers=headers)
response.raise_for_status()
ships = response.json()
print(f"Found {len(ships)} vessels in Strait of Hormuz")
return ships
# Test the function
vessels = get_ships_in_hormuz()
Gotcha: MarineTraffic free tier rate-limits to 1 request/minute. For production, upgrade to the Developer plan ($99/month) or switch to AIS Stream which offers WebSocket connections.
Step 3: Structure Geopolitical Context for Claude
Claude excels at reasoning over complex situations when given structured context. Compile ship data alongside news mentions:
from anthropic import Anthropic
import json
client = Anthropic(api_key=os.getenv("ANTHROPIC_API_KEY"))
def analyze_disruption_risk(vessels, recent_news):
"""Use Claude to assess maritime disruption severity."""
# Prepare structured vessel summary
vessel_summary = {
"total_count": len(vessels),
"vessel_types": {},
"flags": {},
"stationary_count": 0
}
for v in vessels:
# Count by type
vtype = v.get("TYPE_SUMMARY", "Unknown")
vessel_summary["vessel_types"][vtype] = vessel_summary["vessel_types"].get(vtype, 0) + 1
# Count by flag
flag = v.get("FLAG", "Unknown")
vessel_summary["flags"][flag] = vessel_summary["flags"].get(flag, 0) + 1
# Check if vessel is stopped (speed 10."""
severity = analysis["severity_score"]
stationary = analysis.get("stationary_vessel_count", 0)
if severity >= 7 or stationary > 10:
twilio_client = Client(
os.getenv("TWILIO_ACCOUNT_SID"),
os.getenv("TWILIO_AUTH_TOKEN")
)
message_body = f"""⚠️ STRAIT OF HORMUZ ALERT
Severity: {severity}/10
Stationary vessels: {stationary}
Recommendation: {analysis['recommendations'][0]}
Timeline: {analysis['timeline_estimate']}"""
message = twilio_client.messages.create(
body=message_body,
from_=os.getenv("TWILIO_FROM_NUMBER"),
to=os.getenv("ALERT_TO_NUMBER")
)
print(f"Alert sent: {message.sid}")
return True
print("No alert necessary (severity below threshold)")
return False
⚠️ WARNING: Twilio charges $0.0079/SMS for U.S. numbers. Set a monthly budget cap in your account dashboard to avoid surprise bills.
Step 5: Automate with Scheduled Monitoring
Deploy as a GitHub Action that runs every 30 minutes:
# .github/workflows/monitor-hormuz.yml
name: Monitor Strait of Hormuz
on:
schedule:
- cron: '*/30 * * * *' # Every 30 minutes
workflow_dispatch: # Manual trigger option
jobs:
check-disruptions:
runs-on: ubuntu-latest
steps:
- uses: actions/checkout@v4
- name: Set up Python
uses: actions/setup-python@v5
with:
python-version: '3.11'
- name: Install dependencies
run: pip install -r requirements.txt
- name: Run monitoring script
env:
ANTHROPIC_API_KEY: $
MARINETRAFFIC_API_KEY: $
TWILIO_ACCOUNT_SID: $
TWILIO_AUTH_TOKEN: $
TWILIO_FROM_NUMBER: $
ALERT_TO_NUMBER: $
run: python monitor.py
Add your API keys to repository secrets under Settings → Secrets and variables → Actions.
Gotcha: GitHub Actions free tier includes 2,000 minutes/month. Running every 30 minutes consumes ~60 minutes/month, well within limits.
Step 6: Add Historical Context for Better Predictions
Enhance Claude’s analysis by storing past disruption patterns:
import pandas as pd
from datetime import datetime
def log_analysis(analysis, vessels):
"""Append analysis to historical CSV for trend detection."""
log_entry = {
"timestamp": datetime.utcnow().isoformat(),
"severity": analysis["severity_score"],
"vessel_count": len(vessels),
"stationary_count": analysis.get("stationary_vessel_count", 0),
"timeline_estimate": analysis["timeline_estimate"]
}
df = pd.DataFrame([log_entry])
df.to_csv("hormuz_history.csv", mode='a', header=not os.path.exists("hormuz_history.csv"), index=False)
# Feed last 7 days of data back to Claude for pattern recognition
if os.path.exists("hormuz_history.csv"):
history = pd.read_csv("hormuz_history.csv")
recent = history.tail(336) # Last 7 days at 30min intervals
return recent.to_dict('records')
return []
Pro tip: After 2 weeks of data collection, add a weekly summary job that uses Claude to identify recurring patterns (e.g., “Severity spikes every Friday 14:00 UTC correlate with OPEC announcements”).
Practical Example: Complete Monitoring Script
Here’s the full monitor.py orchestrating all components:
#!/usr/bin/env python3
import os
from dotenv import load_dotenv
from datetime import datetime
# Import our custom functions
from maritime_api import get_ships_in_hormuz
from claude_analysis import analyze_disruption_risk
from alerts import send_alert_if_critical
from logging_utils import log_analysis
load_dotenv()
def main():
print(f"[{datetime.utcnow()}] Starting Strait of Hormuz monitor...")
# Step 1: Fetch current vessel positions
vessels = get_ships_in_hormuz()
# Step 2: Gather recent news context (placeholder - integrate News API)
news_context = """Trump announces U.S. Navy escort operations starting Monday.
Previous Hormuz blockades averaged 4.2 days duration (2019-2024 data)."""
# Step 3: Run Claude analysis
analysis = analyze_disruption_risk(vessels, news_context)
# Step 4: Log for historical tracking
history = log_analysis(analysis, vessels)
# Step 5: Send alert if critical
alert_sent = send_alert_if_critical(analysis)
print(f"Analysis complete. Severity: {analysis['severity_score']}/10")
print(f"Alert sent: {alert_sent}")
return analysis
if __name__ == "__main__":
result = main()
Run manually: python monitor.py. Expected output:
[2026-05-04 10:30:00] Starting Strait of Hormuz monitor...
Found 47 vessels in Strait of Hormuz
Disruption severity: 6/10
No alert necessary (severity below threshold)
Analysis complete. Severity: 6/10
Alert sent: False
Key Takeaways
- Maritime AIS data + LLM reasoning creates actionable intelligence systems that outperform keyword-based alerts by contextualizing raw vessel counts with geopolitical events
- Claude Sonnet 3.5’s structured output (with JSON mode) costs ~$0.05 per analysis run, making continuous monitoring economically viable even for small teams
- Threshold automation prevents alert fatigue—only notify when severity ≥7 or anomalies exceed historical patterns by 2+ standard deviations
- Historical logging transforms a simple alert system into a predictive tool that learns disruption patterns specific to each chokepoint
What’s Next
Extend this system to monitor all 8 critical maritime chokepoints simultaneously (Suez Canal, Panama Canal, Malacca Strait) by parallelizing API calls with asyncio—tutorial coming next week.
Key Takeaway: By combining AIS ship tracking APIs with Claude’s contextual reasoning, you can build an automated alert system that monitors geopolitical maritime chokepoints and triggers notifications when route disruptions occur—critical for supply chain professionals navigating the Strait of Hormuz crisis.
